Consensus-clustering rank selection for NMF (Brunet 2004)

The bioinformatics-standard stability approach to choosing the NMF rank. A lightweight engine like nmfkc.ecv / nmfkc.bicv: it returns one stability score per rank and nothing more.

For each rank, NMF is run nrun times from different random initializations (X.init = "runif"). Each run gives a hard clustering of the samples (the column \(\arg\max\) of the coefficient matrix). Averaging the \(N \times N\) connectivity matrices (1 if two samples share a cluster) over the runs yields the consensus matrix; its crispness measures how reproducible the clustering is. Two summaries are reported per rank:

cophenetic: the cophenetic correlation coefficient (CPCC) of the consensus matrix (Brunet et al. 2004). Close to 1 = stable.
dispersion: the Kim & Park (2007) dispersion \(\frac{1}{N^2}\sum_{ij} 4 (C_{ij} - 1/2)^2 \in [0, 1]\); 1 when every consensus entry is exactly 0 or 1 (perfectly crisp).
pac: the Proportion of Ambiguous Clustering (Senbabaoglu et al. 2014) – the fraction of off-diagonal consensus entries falling in the ambiguous interval pac.range (default \((0.1, 0.9)\)). Lower is better (less ambiguity); a more sensitive readout than cophenetic, which tends to saturate.

Unlike the cross-validation engines (where the rank minimizes the error), here a good rank maximizes stability, or is the largest rank before it drops.

Usage

nmfkc.consensus(
  Y,
  A = NULL,
  rank = 2:4,
  nrun = 30,
  keep.consensus = FALSE,
  ...
)

Arguments

Y: Observation matrix (\(P \times N\)), non-negative.
A: Optional covariate matrix passed to nmfkc.
rank: Integer vector of ranks to evaluate (\(\ge 2\)).
nrun: Number of random-initialization runs per rank (default 30).
keep.consensus: Logical; if TRUE also return the list of consensus matrices (one \(N \times N\) matrix per rank).
...: Advanced options, rarely needed (defaults in parentheses): seed (123, base seed; run \(r\) of rank index \(i\) uses seed + 1000 * i + r) and pac.range (c(0.1, 0.9), the ambiguous interval \((u_1, u_2)\) for the PAC measure). Any other arguments are passed to nmfkc (e.g.\ maxit); X.init is forced to "runif".

Value

An object of class "nmfkc.consensus" (a list) with:

cophenetic: Cophenetic correlation coefficient for each rank.
dispersion: Dispersion coefficient (\([0, 1]\)) for each rank.
pac: Proportion of Ambiguous Clustering (\([0, 1]\), lower is better) for each rank.
rank: The evaluated rank vector.
nrun: Number of runs per rank.
consensus: List of consensus matrices, or NULL.

It has print.nmfkc.consensus and plot.nmfkc.consensus (type = "criteria" / "heatmap") methods.

References

Brunet, J.-P., Tamayo, P., Golub, T. R., Mesirov, J. P. (2004). Metagenes and molecular pattern discovery using matrix factorization. PNAS 101(12):4164–4169. doi:10.1073/pnas.0308531101 . Kim, H., Park, H. (2007). Sparse non-negative matrix factorizations ... Bioinformatics 23(12):1495–1502. Senbabaoglu, Y., Michailidis, G., Li, J. Z. (2014). Critical limitations of consensus clustering in class discovery. Sci. Rep. 4:6207. doi:10.1038/srep06207 .

Examples

# \donttest{
Y <- t(as.matrix(iris[, 1:4]))
cs <- nmfkc.consensus(Y, rank = 2:5, nrun = 20, keep.consensus = TRUE)
#> consensus: ranks 2,3,4,5, 20 runs/rank (Brunet 2004); 80 fits total...
cs                       # stability table per rank
#> Consensus rank selection (Brunet 2004), 20 runs/rank
#>   best: dispersion max = rank 4 | PAC min = rank 5
#>  rank cophenetic dispersion   pac
#>     2      0.960      0.581 0.476
#>     3      0.970      0.594 0.462
#>     4      0.945      0.622 0.419
#>     5      0.951      0.621 0.399
plot(cs)                 # type = "criteria": stability curves

plot(cs, type = "heatmap")            # all ranks, n2mfrow grid

plot(cs, type = "heatmap", rank = 3)  # one rank, with labels

# }
